Earth Insulation Tester
For 10kV Professional Insulation Tester With Large Capacity
By2677E insulation resistance tester is designed and developed to evaluate the electrical insulation quality of large-scale high-voltage transformer, motor, generator, long-distance power cable, tubular bus and other electrical insulation quality under strong interference in high-voltage substation and power plant.
It is especially suitable for the test site with large capacity and strong interference above 110kV.
Features
1. Wide voltage range: 1KV,2.5KV,5KV,10KV
2. can test up to 2TΩ insulation resistance
3. 3½ LCD digital display of insulation resistance value
4. auto shift resistance measuring range
5. environment temperature can be measured
6. self-clocking function, short buzz every 15 seconds
7. auto calculate and save R15S, R60S, R600S, DAR and Polarization Index
8. Output short-circuit current≥3mA which meets fast charging request to capacitive load
9. strong anti-interference ability, stable and reliable reading
10. perfect protection, safe for operation
11. powered by rechargeable Li-battery, auto power off when battery energy is not enough
Technical Indicators
1. Power dissipation of the entire machine: ≤10W
2. Working temperature and humidity: 0℃～40℃; ≤ 85 % RH
3. Withstand: AC2.5kV 50HZ 1min
4. Working Power supply: 14.8V(2.2Ah) rechargeable Li-battery
5. Charging supply: AC200V,50HZ (±10 %) (can be customized)
6. Size and weight: 270mm(L)×210mm(W)×100mm(D) 2kg
| Rated voltage(V) | 1000 | 2500 | 5000 | 10000 |
| Working voltage(V) | Rated voltage×(1±10%) |
| Measuring range | 0～200GΩ | 0～500GΩ | 0.001～1000GΩ | 0.001～1999GΩ |
| Max error:±10%RDG+1d (max display value: 1999) |
| Short circuit output current | ≥1.5mA | ≥1.5mA | ≥3mA | ≥3mA |
| absorption ratio, polarization index | Measuring range 0.1～19.99, max error:±2%RDG+1d |
